Real time detection of laser light intensity, temperature, and humidity;
Equipped with indicator light driven output, it can directly load indicator light laser;
Alarm parameters can be set and current sensor data can be read through RS485/CAN communication;
The indicator photocurrent can be set through communication;
When an alarm is triggered, it responds quickly and reliably through the fault bus to protect the laser;
We can increase the number of testing items and sensors required according to customer needs.
Accurately detect key parameters such as laser intensity, temperature and humidity, support RS485/CAN communication for remote setting of alarm thresholds, and ensure the safe operation of the system.
Integrated indicator light drive function, communication adjustable current, fast response to fault bus, achieving multiple protections for laser.
Modular design supports increasing the number of detection items and sensors as needed, adapting to diverse customer needs.
| Model | PS1 | PS1 | PS3 |
|---|---|---|---|
| Input voltage | DC24V±1V | ||
| Light detection | 1 Road light intensity detection | 4 Road light intensity detection | 4 Road light intensity detection |
| Temp detection | 1 Road Temperature Detection | 4 Road Temperature Detection | 4 Road Temperature Detection |
| Temp/humidity | 1 Humidity detection of road temperature | 无 | 1Humidity detection of road temperature |
| Indicator | 无 | 1 Road red light | 1 Road red light |
| Communication | RS485 | CAN | RS485/CAN |
| Alarm | Fault bus+communication | ||
| Temperature | Temperature：-25-60℃；StorageTemperature：-40-85℃ | ||
| Humidity |
Work：20-90%RH，No condensation Storage：10-95%RH，No condensation |
||
| Volume | 85×60×10mm | 100×50×10mm | |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
